Performance & Range
Performance & Range
Hub Motor: 750W brushless hub motor
Power: Max 1000W, Rated 750W
Top Speed: 28mph (Pedal-Assist) | 20mph (Throttle)
Range: Up to 50 miles (Tested with a full charge carrying a 165lb rider on a flat road without wind, at an average speed of 9mph or 15km/h.)
Pedal Assist: 3 level pedal assist with Torque Sensor
Throttle: Thumb
Battery & Charging
Battery & Charging
Battery: 16Ah
Voltage: 48V
Charger: 48V, 3 Amp NIU smart charger (100-240V AC)
Battery Charge Time: 6h
Battery Type: Single Battery
Drivetrain & Gearing
Drivetrain & Gearing
Drive System: Chain Drive
Crank Set: 46T aluminum crankset
Freewheel: 8-Speed Freewheel 12-32T
Derailleur: Shimano 8 speed
Gearing: 8-Speed mechanical (plus 3 electric assist levels)
Frame & Construction
Frame & Construction
Frame Material: 6061 Aluminum alloy
Net Weight: 79lbs
Payload: 308 lbs (140 kg)
Fork: Lockable 80mm Front Fork
Braking System
Braking System
Brake Type: Front and Rear Hydraulic Disc Brakes
Brake Calipers: Hydraulic Disc Brakes
Brake Rotors: 180 mm front and rear
Wheels & Tires
Wheels & Tires
Tires: NIU 26 x 4.0in puncture-resistant tires
Rims: Double-wall aluminum alloy, 36 hole
Spokes: 12-gauge stainless steel
Tire Width: 4.0in
Cockpit & Controls
Cockpit & Controls
Handlebar: Height 45.59in
Grips: Comfortable ergonomic grips
Headset: Sealed Bearing Headset, 1-1/8in straight steerer tube
Comfort & Adjustability
Comfort & Adjustability
Saddle: Comfortable ergonomic saddle
Seatpost: 30.9 x 350 x 2.6T aluminium alloy
Seatpost Clamp: Quick release
Adjustable Seat Height: Seat: Adjustable Seat Height (34.6~43.9in)
Adjustable Handlebar Angle: N/A
Suspension: Lockable 80mm Front Fork
Display & Connectivity
Display & Connectivity
Display: TFT Colorful Display
App Connected: APP Connected
USB Ports: Integrated, under display, 5V/500 MA
Controller: NIU frame-integrated controller
Wiring: Water resistant connectors and wiring harness
Lighting & Safety
Lighting & Safety
Front Light: NIU ICONIC HALO Daytime Running headlight
Rear Light: Integrated taillight with brake light
Reflectors: Pedals with reflectors
Horn/Bell: Mechanical Bell
Accessories & Utility
Accessories & Utility
Fenders: Included, black aluminum alloy front and rear, full coverage
Racks: Rear included, 66lb (30kg) carrying capacity
Kickstand: Heavy-duty aluminum with wide plastic foot
Pedals: Aluminum pedal with reflectors, 9/16"
Durability & Protection
Durability & Protection
Waterproof Rating: IP45 for whole bike, IP67 Battery,IP65 Drive Unit
Component Protection: Water resistant connectors and wiring harness
Warranty: 2-Year Comprehensive Warranty
Drive System Durability: Shimano 8-speed
